Spectroscopy Systems · Spin-Flex

X-band Pulsed ESR / EPR

A modular pulse EPR spectrometer that puts the entire spectrometer inside a single PC — from S-band to W-band.

Introduction

Pulse EPR, reimagined as a compact modular system.

The spinUP platform is a modular pulse EPR spectrometer. Microwave bridges for different frequency bands connect to a single computer that generates, controls and acquires every experiment.

It is designed for research groups who need advanced pulse capability without the footprint and complexity of traditional systems.

System performance

Fast, precise pulse control.

250 MHzBandwidth

0.5 nsArbitrary waveform resolution

5 nsMinimum pulse length

10–100 nsDead time

Frequency bands

One platform, four bands.

Band	Frequency	Max output power
S + C	2–6 GHz	30 W
C + X	6–12 GHz	30 W
Q	32–38 GHz	10 W
W	92–96 GHz	1 W

X-band pulsed ESR microwave bridge — X-band microwave bridge. Image: Spin-Flex.

Software

Ready-made experiments, open scripting.

Pre-programmed pulse sequences, phase cycling of up to 128 steps and MATLAB™ scripting for custom experiments.

FIDHahn echoInversion recoveryDEERENDORCPMGEDMRODMR

Key features

Built for modern spin research.

Entire spectrometer in a PC

Pulse generation, control and acquisition in a single computer.

Modular bridges

Add frequency bands as research needs evolve.

Advanced sequences

DEER, ENDOR, CPMG and more, ready to run.

Phase cycling

Up to 128 phase-cycling steps.

MATLAB™ scripting

Full flexibility to design new experiments.

Compact footprint

Fits research labs without dedicated infrastructure.

Product information referenced from Spin-Flex. Final configuration and specifications are confirmed by NB Instrument per requirement.
